    Offline Capability enabled for iOS App Development

    JennyBy JennyNovember 11, 2020Updated:April 3, 2021No Comments11 Mins Read
    Facebook Twitter Pinterest LinkedIn Tumblr Email
    Share
    Facebook Twitter LinkedIn Pinterest Email

    Offline features in iOS are one of the best features which can be utilized when offline syncing data is required. Data can be saved in a persistent manner and utilized in offline mode. Offline Sync can be a push and pull the data from the server. Auto syncing data when a user comes offline to online mode. Offline is useful when the user needs the data when network connectivity goes So developer need to design the iOS app development services in such a way that all the data can be saved in the offline mode inside core data, cache and in the file system but most of cases developer used to saved data in core data because it can accommodate large data

    Library to handle Offline

    • Networking
    • Coredata
    • Keychain

    Offline data can be saved in various places iOS

    • Property List
    • SQLite
    • Core Data
    • NSUser Defaults
    • Key Chain

    Benefit of Offline

    • Auto Sync data
    • Pull and Push data
    • Data saved offline and access online
    • Cache and database can be used for offline
    • Offline to Online syncing

    Offline implementation using Reachability

    1.Identifier for the notifications triggered by Reachability Online Offline. The Notification info will contain a dictionary with the keyReachabilityStatusOfflineOnlineChangedthat will contain a description of the current connection status. Closure type definition for ReachabilityOnlineOffline status updates

    public let ReachabilityOnlineOfflineDidChangeNotification = “com.xyz.ReachabilityOnlineOffline.change”

    public typealiasReachabilityOnlineOfflineClosure = (_ reachable: Bool, _ status: ReachabilityStatusOfflineOnline) -> Void

    2.Enum with the possible status of the internet connection monitored byReachabilityOnlineOffline

    public enumReachabilityStatusOfflineOnline

     {

        case notReachable

        case reachableViaWWan

        case reachableViaWifi

        public var description: String {

            switch self

    {

                case .reachableViaWWan:

                    return “ReachableViaWWan”

                case .reachableViaWifi:

                    return “ReachableViaWifi”

                case .notReachable:

                    return “NotReachable”

            }

        }

    }

    3. Class for monitoring if an internet connection is present. Var for accessing the ReachabilityOnlineOffline singleton the default host for monitoring reachability is “XYZ.com”.This var holds a closure for receiving reachability changes. Var for verifying if the internet is reachable. Var with information about the current internet connection

    public class ReachabilityOnlineOffline {

        private var _isReachable: Bool = false

        private var _reachabilityStatus: ReachabilityStatusOfflineOnline = .notReachable

        private var scNetworkReachability: SCNetworkReachability?

        public static let instance = ReachabilityOnlineOffline()

        public var reachabilityClosure: ReachabilityOnlineOfflineClosure?

        public var isReachable: Bool {

            return self._isReachable

        }

        public var reachabilityStatus: ReachabilityStatusOfflineOnline {

            return self._reachabilityStatus

        }

        private init() {

            let defaultHost = “xyz.com”

            guard let addressReachability = ReachabilityOnlineOffline.createReachabilityWithHost(defaultHost) else {

                return

            }

    self.scNetworkReachability = addressReachability

        }

    3. Reachability with address need to check to reachability

        private static funccreateReachabilityWithAddress(_ address: sockaddr_in) ->SCNetworkReachability? {

            var addr = address

            guard let networkReachability = withUnsafePointer(to: &addr, {

                $0.withMemoryRebound(to: sockaddr.self, capacity: 1) {

    SCNetworkReachabilityCreateWithAddress(nil, $0)

                }

            }) else {

                return nil

            }

            return networkReachability

        }

    4. Reachability with host needs to found and Reachability can check whether wifi connected or not whether it is offline or online. If it is offline then not reachbale wiil come where data can be saved

        private static funccreateReachabilityWithHost(_ host: String) ->SCNetworkReachability? {

            let hostToReach = host

            var host = hostToReach

            guard let networkReachability = withUnsafePointer(to: &host, {_ in

    SCNetworkReachabilityCreateWithName(nil, hostToReach)

            }) else {

                return nil

            }

            return networkReachability

        }

        private static funcstatusFromReachabilityFlags(_ flags: SCNetworkReachabilityFlags) ->ReachabilityStatusOfflineOnline {

            var status: ReachabilityStatusOfflineOnline

            let isConnectionRequired = flags.contains(.connectionRequired)

            let isReachable = flags.contains(.reachable)

            let isReachableViaWwan = flags.contains(.isWWAN)

            if !isConnectionRequired&&isReachable {

                if isReachableViaWwan {

                    status = .reachableViaWWan

                } else {

                    status = .reachableViaWifi

                }

            } else {

                status = .notReachable

            }

            return status

        }

        private static funcisReachableFromStatus(_ status: ReachabilityStatusOfflineOnline) -> Bool {

            switch status {

                case .reachableViaWifi:

                    return true

                case .reachableViaWWan:

                    return true

                default:

                    return false

            }

        }

        private static funchandleReachabilityStatusUpdate(_ pointer: UnsafeMutableRawPointer, isReachable: Bool, reachabilityStatus: ReachabilityStatusOfflineOnline) {

                let selfInstance = Unmanaged<ReachabilityOnlineOffline>.fromOpaque(pointer).takeUnretainedValue()

    selfInstance._isReachable = isReachable

    selfInstance._reachabilityStatus = reachabilityStatus

    NotificationCenter.default.post(name: Notification.Name(rawValue: ReachabilityOnlineOfflineDidChangeNotification),

                    object: nil,

    userInfo: [“ReachabilityStatusOfflineOnlineChanged”: reachabilityStatus.description])

    DispatchQueue.main.async(execute: { () -> Void in

    selfInstance.reachabilityClosure?(selfInstance.isReachable,

    selfInstance.reachabilityStatus)

                })

        }

        private funcgetReachabilityFlags() ->SCNetworkReachabilityFlags? {

            guard let reachability = scNetworkReachability else {

                return nil

            }

            var flags = SCNetworkReachabilityFlags()

            if !SCNetworkReachabilityGetFlags(reachability, &flags) {

                return nil

            }

            return flags

        }

    5. A method that starts monitoring reachability of the default address, a custom host or custom address For setting a host for reachability, call setHostForReachability and supply a host as String, ie: “xyz.com”. For setting a custom address for reachability, call setAddressForReachability and supply a sockaddr_in with the address or monitoring reachability

        public funcstartMonitoring() {

    self.stopMonitoring()

            guard let reachability = self.scNetworkReachability else {

                self._isReachable = isReachable

                self._reachabilityStatus = reachabilityStatus

                return

            }

            var scNetworkContext = SCNetworkReachabilityContext(version: 0, info: nil, retain: nil, release: nil, copyDescription: nil)

            scNetworkContext.info = UnsafeMutableRawPointer(Unmanaged.passRetained(self).toOpaque())

    SCNetworkReachabilitySetCallback(reachability, { (reachability, flags, info) in

                    let reachabilityStatus = ReachabilityOnlineOffline.statusFromReachabilityFlags(flags)

                    let isReachable = ReachabilityOnlineOffline.isReachableFromStatus(reachabilityStatus)

                    let selfInstance = Unmanaged<ReachabilityOnlineOffline>.fromOpaque(info!).takeUnretainedValue()

                    if selfInstance.isReachable != isReachable {

    ReachabilityOnlineOffline.handleReachabilityStatusUpdate(info!,

    isReachable: isReachable,

    reachabilityStatus: reachabilityStatus)

                    }

                },

    &scNetworkContext)

    SCNetworkReachabilityScheduleWithRunLoop(reachability, CFRunLoopGetMain(), CFRunLoopMode.commonModes.rawValue)

        }

    6. Stops ReachabilityOnlineOffline of monitoring for internet connection changes

        public funcstopMonitoring() {

            guard let reachability = self.scNetworkReachability else {

                return

            }

    SCNetworkReachabilityUnscheduleFromRunLoop(reachability, CFRunLoopGetMain(), CFRunLoopMode.commonModes.rawValue)

        }

    7. Sets a host for monitoring reachability, when this method is called, reachability monitoring is stopped. You should call startMonitoring() after setting a new host

    – parameter host: a host for monitoring reachability with the format “host.domain” ie: “xyz.com”

        public funcsetHostForReachability(_ host: String) {

    self.stopMonitoring()

    self.scNetworkReachability = nil

            guard let hostReachAbility = ReachabilityOnlineOffline.createReachabilityWithHost(host) else {

                return

            }

    self.scNetworkReachability = hostReachAbility

        }

    8. Sets an address for monitoring reachability, when this method is called, reachability monitoring is stopped you should call startMonitoring() after setting a new address – parameter address: an address for monitoring reachability with the format “host.domain” ie: “xyz.com”

        public funcsetAddressForReachability(_ address: sockaddr_in) {

    self.stopMonitoring()

    self.scNetworkReachability = nil

            guard let addressReachability = ReachabilityOnlineOffline.createReachabilityWithAddress(address) else {

                return

            }

    self.scNetworkReachability = addressReachability

        }

    9. Perform a synchronous check to determine the current reachabillity state via reachability flags.

    • parameter shouldNotify: a Boolean value to indicate whether the application should be notified via the usual channels (notification, closure) if a change in reachability is detected via synchronous check
    • Returns: boolean value indicative of whether device is considered reachable based on reachability flags

        public funcperformSynchronousReachabilityCheck(shouldNotify: Bool) -> Bool {

            guard let reachabilityFlags = getReachabilityFlags() else { return false }

            let reachabilityStatus = ReachabilityOnlineOffline.statusFromReachabilityFlags(reachabilityFlags)

            let isReachable = ReachabilityOnlineOffline.isReachableFromStatus(reachabilityStatus)

            if shouldNotify, self.isReachable != isReachable {

                self._isReachable = isReachable

                self._reachabilityStatus = reachabilityStatus

    NotificationCenter.default.post(name: Notification.Name(rawValue: ReachabilityOnlineOfflineDidChangeNotification),

                                                object: nil,

    userInfo: [“ReachabilityStatusOfflineOnlineChanged”: reachabilityStatus.description])

    DispatchQueue.main.async(execute: { () -> Void in

    self.reachabilityClosure?(self.isReachable,

    self.reachabilityStatus)})

            }

            return isReachable

        }

    }
